Mikrotik CRS309-1G-8S+ Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White (CRS309-1G-8S+IN)
Part number:
CRS309-1G-8S+IN
EAN:
4752224002143
> Managed
> Basic switching RJ-45 Ethernet ports quantity: 1 Console port: RS-232
> 10G support
> Switching capacity: 162 Gbit/s
> Rack mounting
> Power over Ethernet (PoE)
Please contact us by phone or e-mail in order to determine the details.
Description
Mikrotik CRS309-1G-8S+ Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) White
Desktop switch with one Gigabit Ethernet port and eight SFP+ 10Gbps ports
The CRS309-1G-8S+ is a very compact, yet powerful networking switch. It has eight SFP+ slots, supporting up to 10 Gbit module in each, which results in a total switching capacity of 162 Gbps and total non-blocking throughput of 81 Gbps.
The device also has dual-core 800 MHz CPU, 512 MB RAM, a management Ethernet port with PoE power input, RS232 serial port, a grounding terminal and is capable of dual boot (choose which operating system you prefer, RouterOS, or SwOS).
Multimedia
Leaflets:
Other Digital Assets:
Specifications
Management features
Switch type
Managed
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
1
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity
8
Console port
RS-232
Power connector
DC-in jack
Network
Networking standards
IEEE 802.3af, IEEE 802.3at
10G support
Yes
Data transmission
Switching capacity
162 Gbit/s
Design
Rack mounting
Yes
Product color
White
Performance
Built-in processor
Yes
Processor frequency
800 MHz
Memory type
RAM
Internal memory
512 MB
Flash memory
16 MB
Power
DC input voltage
12 - 57 V
Output current
1.2 A
Power consumption (max)
23 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) voltage range
18 - 57 V
Operational conditions
Operating temperature (T-T)
-40 - 70 °C
Weight & dimensions
Width
5.55" (141 mm)
Depth
4.53" (115 mm)
Height
1.1" (28 mm)
Packaging data
Screws included
Yes
Mounting brackets included
Yes
AC adapter included
Yes
SKU:
1045716
